Convenient management: The user-friendly playlist creation software is convenient for the management and control of advertisement playback. Play log to facilitate understanding of the playback situation.
Item No.:
PPC2020005Product origin:
ChinaColor:
BlackShipping port:
guangzhouLead Time:
71.High integration. Integrate USB/LVDS/eDP/Ethernet/HDMI/WIFI/Bluetooth in one, simplify the design of the whole machine, and insert TF card.
2.Built-in PCI-E 3G module. Supports a variety of PCI-E 3G/4G modules such as Huawei and Longshang, which are more suitable for remote maintenance of advertising integrated machines and save labor costs.
3.Rich expansion interface. 6 USB interfaces (4 pins, 2 standard USB ports), 3 expandable serial ports, GPIO/ADC interface, which can meet the requirements of various peripherals on the market.
4.High definition. Supports up to 3840x2160 decoding and various LVDS/eDP interface LCD displays
5.full functioning. Support horizontal and vertical screen playback, video split screen, rolling subtitles, time switch, USB data import and other functions.
6.Convenient management: The user-friendly playlist creation software is convenient for the management and control of advertisement playback. Play log to facilitate understanding of the playback situation.
|
project |
description |
|
Display performance |
Display size 23.8 inches 16:10 widescreen Maximum resolution 1920*1080 Brightness 250cd/m2 Contrast ratio 1000:1 |
|
Capacitive touch screen |
Full plane multi-touch |
|
CPU |
Rockchip RK3288 The strongest quad-core 1.8GHz Cortex-A17 quad-core GPU Mail-T764 |
|
RAM |
DDR3 2G/ 4G (optional, all available in stock) |
|
Built-in memory |
EMMC 16G/ 32G (optional, all available in stock) |
|
Memory expansion |
Supports up to 64GB TF card expansion |
|
Built-in ROM |
2KB EEPROM |
|
Decoding resolution |
Support up to 3840*2160 |
|
operating system |
Android 6.0.1 |
|
Play mode |
Support multiple playback modes such as looping, timing, and insertion |
|
Network support |
3G, Ethernet, support WiFi, Bluetooth 4.0, wireless peripheral expansion |
|
Video playback |
Support AVI (H.264, DIVX, DIVX, XVID), rm, rmvb, MKV (H.264, DIVX, DIVX, XVID), WMV, MOV, MP4 (.H.264, MPEG, DIVX, XVID), DAT (VCD format), VOB (DVD format), PMP, MPEG, .MPG, FLV (H.263, H.264), ASF, TS, TP, 3GP, MPG and more than 30 formats |
|
Image Format |
Support JPG, BMP, PNG, GIF and other image format browsing and support rotation/slideshow Play, up to 4096*4096 resolution |
|
USB2.0 interface |
2 USB HOST, 4 USB sockets |
|
MI pi camera |
24pin FPC interface, support 1300w Camera (optional) |
|
Serial port |
Default 3 TTL serial port sockets (can be changed to RS232 or 485) |
|
GPS |
External GPS (optional) |
|
WIFI, BT |
Built-in WIFI, BT4.0 |
|
3G |
Built-in WCDMA, EVDO, 4G full Netcom, support voice calls |
|
Ethernet |
1, 10M/100M/1000M adaptive Ethernet |
|
TF card |
Support TF card |
|
output |
LVDS output 1 single/dual channel, can directly drive 50/60Hz LCD screen
EDP output Can directly drive multiple resolution EDP interface LCD screens
HDMI output 1 unit, support 1080P@120Hz, 4kx2k@60Hz output Audio and video output Support left and right channel output, built-in dual 8R/5W power amplifier |
|
HDMI in |
HDMI input, 30pin FPC custom interface (optional) |
|
RTC real time clock |
stand by |
|
Timer switch |
stand by |
|
System Upgrade |
Support SD card / computer update |
|
Dimensions |
575mm (width) *347mm (height) *66mm (depth) |
|
working environment |
Working temperature: -5 ～ 50℃ Storage temperature: -20 ～ 70℃ Working humidity: 10% ～ 90%, non-condensing |
