Product Overview: P15RW-J2 is a 15 inch fanless industrial tablet computer, which adopts galvanized sheet bending technology, independent mold opening, and the front panel is produced by large CNC precision machining; Ergonomic design, slim and beautiful, streamlined shape, and excellent craftsmanship. The system is based on integrated Intel ® Tiger Lake 11th Core I5-1135G7 2.4GHz quad core eight thread processor, TDP28W, with powerful computing and graphics processing capabilities, industrial grade LCD display screen, high brightness, high contrast, long lifespan and other characteristics; The touch screen adopts a high-temperature process five wire capacitive type, which does not drift, responds quickly, has high accuracy, and ensures a high reliability operating environment. It has good dust prevention, heat dissipation, and anti vibration performance. Industrial tablets are widely used in industrial field environments such as intelligent transportation, industrial automation process control, intelligent power control, CNC equipment manufacturing, environmental monitoring, pharmaceutical equipment, food packaging machinery, machine vision inspection, wind power monitoring, solar crystal pulling furnaces, tire vulcanizing machines, etc.
Item No.:
P15RW-J2Product origin:
中国广州Lead Time:
14天| project |
describe
|
|
Display performance |
Display size 15 inches 4:3 front screen
Maximum resolution 1024 × 768 Brightness 350 cd/m2 Contrast ratio 1000:1 |
| touch screen | Capacitive touch screen |
|
system configuration |
Processor integrated with Intel ® Tiger Lake 11th Core I5-1135G7 2.4GHz quad core eight thread processor, TDP 28W Chipset SOC
Memory 1 * DDR4-3200MT/s notebook memory, Max 32GB |
|
I/O interface |
5 x RJ45 Gigabit Ethernet ports LAN1-5 all use Intel I211AT, LAN1-4 support POE, |
| audio frequency |
Onboard ALC888S 7.1+2-channel high fidelity audio controller, supporting MIC/Line out Power amplifier
It is recommended to use a 2 Ω 3W speaker for the amplifier |
| weight |
5.45kg
|
| Installation method | Embedded, wall mounted, desktop, VESA |
| operating system | Windows 10/Linux |
| External dimensions | 395mm (length) * 96mm (height) * 312mm (width) |
| work environment |
Working temperature/humidity requirements: 0-60 ℃, 10% -90% without condensation Non working temperature/humidity requirements: -25~75 ℃, 5%~95% non condensing |
